Home / REID Lifting Porta-Gantry Rapide® 2200lbs Foldable Mobile Gantry

REID Lifting

REID Lifting Porta-Gantry Rapide® 2200lbs Foldable Mobile Gantry

REID Lifting Porta-Gantry Rapide® 2200lbs Foldable Mobile Gantry

REID Lifting Porta-Gantry Rapide® 2200lbs Foldable Mobile Gantry

$6,767.29

Typically Ships In: 1-2 Business Days

<p>Secure Payment Transaction Guarantee</p>

Secure Payment Transaction Guarantee

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Meta Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
<p>Choose Rapid Shipping at Checkout</p>

Choose Rapid Shipping at Checkout

<p>24/7 U.S. Based <a href="/pages/contact" title="Contact">Customer Service Help</a></p>

24/7 U.S. Based Customer Service Help

Quick Overview:

  • Goods Capacity: 2200lbs
  • Personnel Capacity: 1100lbs
  • Fall Arrest Capacity: 1 or 2 persons (specification dependant)
  • Available in Standard, Medium & Tall heights

Customers Also Bought

Description

Videos

Labelled as ‘the perfect dual solution’ for lifting both goods and personnel, it’s understandable why the PortaGantry Rapide from REID Lifting is taking the industry by storm.

Manufactured from high-grade aluminum, this foldable, height-adjustable gantry crane has been specifically designed to provide users with rapid deployment when and wherever needed. It’s fully portable and boasts an impressive safe goods working load limit range of 2200lbs, and a safe personnel capacity range of 1100lbs (1 or 2 persons fall arrest).

Assembled in a minute by one person (YES THAT’S RIGHT!) – without the requirement of any tools – the PortaGantry Rapide is ideal for confined space access situations thanks to its easy manoeuvrability.

Fitted with durable castors as standard, the frame has been anodized for increased protection against corrosion, making it suitable for an extensive range of industries.

The REID PortaGantry Rapide is also OSHA compliant, as well as ANSI Z359.18-17 compliant for fall arrest applications.

All-in-All, we can’t fault this unique product – safe, sturdy, versatile, and portable, what more could you want from a lifting gantry.



FINISH MY BUILD... WHAT EXTRAS ARE AVAILABLE?



If you're in the market for a complete set-up, why not opt for one of the trolley options. Available for you to include with your PortaGANTRY Rapide is either:



A Master Link Trolley - Reid's Gated (patent pending) Master Link Trolley can be utilised when additional headroom or clearance is not an issue, and the convenience of a large opening for the attachment of various hoists is preferred. This unique and innovative trolley options facilities multiple trolleys to be attached tot he beam after the system has been assembled and can also be locked into position on the beam.



A Closed Coupled Trolley - The patent Pending Gated Closed Coupled Trolley option is more suitable for scenarios when additional headroom or clearance is needed below the beam. This trolley can be attached to the beam after the system has been fully assembled.





Additionally, you can also purchase a Sheave Carrier , which enables the use of winches or retrieval fall arrest devices in conjunction with the Rapide model. They are easily detachable and can incorporate either one (single) or two (double) pulley wheels that act as guides for both cables and ropes.



Finally, we offer a Sheave & Ball Lock Pin Set which can be fitted retrospectively to your PortaGANTRY Rapide enabling winches or retrieval fall arrest devices to be attached to the trap plate of the vertical column.

FAQ's

Q: Looking at the dimension C, why is there an Min and Max dimension. Are the legs spreadable?

A: Yes, one of the A-frames is able to be moved in on the beam to shorten the span. Gantry is used as standard at the max dimension.



  • Goods Capacity: 2200lbs
  • Personnel Capacity: 1100lbs
  • Fall Arrest Capacity: 1 or 2 persons (specification dependent)
  • Easy height adjustment
  • OSHA Compliant
  • ANSI Z359.18-17 Compliant
  • Available in Standard, Medium & Tall heights
  • Integrated castor wheels
  • Anodized for increased corrosion resistance

Downloads
  • REID Lifting PortaGantry Rapide Data Sheet
